1. clothing "identity card", small size, easy to install and operate, so that the entire process controlled target, comprehensive management
2. long-range identification, identification of high sensitivity, fast, with Korfball unique identifier (TID code )
3. is mainly applied to a variety of widely used in clothing, luggage, footwear and other industries
|
● Basic Parameters |
|
| Types | UHF passive RFID tags |
| Working Frequency | 860-960MHz |
| Protocol | ISO / IEC 18000-6C EPC Class1 Gen2 |
|
● Physical Parameters |
|
| Size |
Can be customized |
| Packaging Materials | PET, PVC, Coated paper |
| Antenna | Aluminum etching antenna |
| Craft | 4C Offset printing,Print ID number,Encoding |
|
● Performance Parameters |
|
| Chip | Alien H3, impinjM4D / M4E / M4QT / M5 |
| Storage | Related to the chip |
| Operating mode | Can read and write |
| Data Retetion | > 10 years |
| Write Endurance | 100,000 times |
| Reading Distance | 0-10m (the reading range is related to the working condition and reader) |
|
● Environmental Parameters |
|
| Working temperature | (-25 ℃ ~ + 55 ℃) |
| Storage temperature | (-35 ℃ ~ + 70 ℃) |
|
● Typical Applications |
|
| Applications | Using in Clothing, footware warehouse, in order for products tracking, checking and inventory management |
|
● Package |
|
| Packaging Information | Piece/Roll |
